SparkFun GNSS L1/L5 Breakout - NEO-F10N, SMA - GPS - Galileo - Beidou - 3.3V Logic - Power 5V-3V - Board Dimensions 50.8 mm x 38.1 mm
5.0 (30 items)
Limited Time SaleUntil the end
14
49
55
$25.17 cheaper than the new price!!
Free shipping for purchases over $99 ( Details )
Free cash-on-delivery fees for purchases over $99
Free cash-on-delivery fees for purchases over $99
See all stores
Please note that the sales price and tax displayed may differ between online and in-store. Also, the product may be out of stock in-store.
New $41.95
Product details
| Management number | 209085955 | Release Date | 2026/03/29 | List Price | $16.78 | Model Number | 209085955 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
- Supports concurrent reception of three GNSS constellationstions: GPS, Galileo, and Beidou; Meter-level positional accuracy
- Receives L1/L5 Bands: Improved performance in challenging urban environments; Chooses the best signals from both bands than with L1 alone
- CH340 USB-to-serial converter: Easily connect to computer USB port
- On-board rechargeable battery: Reduce time to first fix from cold start or hot start
- Features: 1x USB Type C Connector; ESD Protection Diodes for USB Data Lines; Integrated SMA Connector; Voltage: 5 V or 3.3 V but all logic is 3.3 V; Current: 21 mA-26 mA (varies with constellations and tracking state); AP2112K 3.3V/600 mA Voltage Regulator; Backup Battery to Aid in Hot Starts; Time to First Fix: 28s (cold); 2s (hot)
- Max Navigation Rate for Single GNSS Configuration (GPS): 20 Hz, Positional Accuracy (GPS): 1.5m, Time Pulse Accuracy: 30ns
- Product requires an antenna: Included an SMA connector for a secure connection; Board Dimensions (not including SMA connector): 50.8 mm x 38.1 mm
